Scatter Plots

A scatter plot, also known as a scatter chart or scatter graph, is a tool for visualizing the relationships between variables. Scatter plots are made by plotting ordered pairs on a coordinate plane (or Cartesian plane).

How to create a scatter plot

To create a scatter plot, all you need is a sheet of paper, a ruler, and a pencil or pen:

Here is an example of data that has been organized by their variables (x,y):

Person's Age in Years ( $x$ )	Annual Income in USD ( $y$ )
32	75,000
40	110,000
35	90,000
36	50,000
37	45,000
39	60,000
34	51,000
39	60,000
41	40,000
45	100,000
47	65,000
49	68,000
53	105,000
55	85,000
43	80,000
44	55,000
50	85,000

And this is the resulting scatter plot:

Scatter plots and correlations

Scatter plots are fantastic ways of finding relationships or correlations between your two variables. You can find outliers in your data, notice groupings of data points, and even draw a line of best fit to more easily visualize correlations, which can be positive or negative as well as weak or strong. You can also find no correlation between variables.

Positive correlations

If the value of the $y$ variable on a scatter plot tends to increase with the value of the x variable (and data points rise from the left of the graph to the right of the graph), the variables are said to have a positive correlation. In the example below, the points are scattered widely, which means the variables also have a weak correlation:

Negative correlations

If the value of the $y$ variable tends to decrease while the value of the $x$ variable increases (and points fall from the left to the right of the graph), the variables are said to have a negative correlation. While a weak correlation shows points widely scattered, a strong correlation shows points closer in proximity.

No correlation

If points on a scatter plot don't appear to have a specific tendency, the variables are said to have no correlation. Here is an example of a scatter plot showing no correlation between variables:

Practice questions on analyzing correlations on scatter plots

a. What does a scatter plot with points that don't seem to rise or fall in any direction show?

No correlation

b. If points on a scatter plot rise from left to right and are close in proximity, what does the data show?

A strong positive correlation between the variables

c. If points show a correlation but are scattered widely, what does this mean?

There is a weak correlation

d. If you graphed women's ages and the number of screwdrivers they own, what type of correlation might you find?

No correlation since these variables are unrelated

e. If you graphed people aged 50 to 80 and their average annual cost of life insurance, what type of correlation might you find?

A strong positive correlation since the annual cost of life insurance often increases steadily for people aged 50+

f. If you graphed the annual cost of auto insurance for drivers aged 16 to 25, what type of correlation might you find?

A strong negative correlation since the annual cost of auto insurance tends to decrease steadily between the ages of 16 and 25.
